Weco Light Curtain High-Quality Production from Panda

Weco Light Curtain

Weco Light Curtain is a high-performance safety device designed to protect personnel and equipment in automated systems, particularly elevators and industrial machinery.

High Precision

Reliable object detection for enhanced safety.
Fast Response

Immediate shutdown to prevent hazards.
Durable Design

Resistant to dust, moisture, and interference.
Easy Installation

Flexible mounting options for various applications.
Compliance

Meets international safety standards (e.g., IEC 61496).

Elevator Parts

HOT PRODUCTS

Elevator Car Door Operator Center opening OMJ102A

Elevator Leveling Sensor

Set A Consultation Today

*We respect your confidentiality and all information are protected.

Send

Description

Reviews

Basic Information

Type	Weco Light Curtain	MOQ	1pc
Model	Weco 917A	Shipping	FCL/LCL
Voltage	AC110V	Package	Standard package
Thickness	11mm	Warranty	1 year

Specification

Technical Features		917A6	917A7
Number of Infra Red Diodes		17 Diodes	32 Diodes
Response Time	Relay Output	45ms	61ms
	Transistor Output	21ms	37ms
Scanning Beams		94-33 Beams	154-94 Beams
Infrared Diodes Range		117.5mm	58.8mm
The Mimimum Door Opening		≤20mm
The Maximum Door Opening		≥1800mm
Redundancy (one transimitter shielded after 120s detected absent)		NO	YES
Detecting Range		0-4000mm
Operation Temperature		-20℃~+65℃
Light Immunity		100000 Lux
Protection Level		IP54
EMC ( EN12015 EN12016)		General circuit level
LED Interpretation		1. Yellow LED and Red LED in Receiver on when blocked or in malfunction. 2. Yellow LED in receiver on and Red LED in receiver off without block.
